CINEMA 30 е флагманът на Marantz с 11.4 канала, произведен в Япония с мощност от 140W 0.05% THD, Dolby Atmos, DTS:X, 8K Ultra HD, HEOS поддръжка, Dirac Live и MultEQ XT32.
Marantz Cinema 30 e най-добрият избор за кино ентусиасти, които ценят безкомпромисния звук и видео изживяване.
CINEMA 30 е най-усъвършенстваният AV ресивър, създаван някога от Marantz, който предефинира звученето на системите за домашно кино от най-висок клас. Създаден с помощта на патентовани технологии, усъвършенствани през десетилетия на богати традиции, той разполага с 11.4 канала, осигуряващи несравнима производителност и способност без усилие да захрани дори мащабни системи за домашно кино. Дискретните схеми HDAM SA-2, двойното цифрово-аналогово преобразуване (dual-DAC) и монолитният симетричен усилвател го издигат до най-високото ниво на производителност, постигано някога от Marantz.
- Произведен в Ширакава, Япония
- 11.4 канала
- 140 вата на канал
- 7 HDMI входа (всички 8K) плюс eARC
- 8K и Dolby Atmos
- Вградена HEOS функционалност
Гаранция 2 години
| Size and Weight | |
|---|---|
| Dimensions - Antenna:Horizontal (HxWxD) | 442mm x 457mm x 189mm |
| Dimensions - Antenna:Vertical (HxWxD) | 442mm x 457mm x 257mm |
| Dimensions - W/o Antenna (HxWxD) | 442mm x 447mm x 189mm |
| Weight | 8.7kg |
Power Amplifier |
|
| Number of Powered Channels | 11 |
| Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive) | - |
| Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive) | 140 W |
| Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) | 175 W |
| Power Output (6 ohm, 1 kHz, 10% 1ch Drive) | 250 W |
| 70% Guarantee | Yes |
| Discrete Power Amplifier | Yes |
| Amplifier Topology | Class A/B |
| Current Feedback Topology | Yes |
| Bi-Amp Drive | assignable |
Multichannel Surround Technologies |
|
| DTS | DTS HD Master, DTS:X, DTS:X Pro, DTS Neural:X, DTS Virtual:X |
| Dolby | Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music, Dolby Surround |
| Max Number of Processing (Preamp) Channels | 13.4 |
| IMAX Enhanced | Yes |
| Auro 3D | Yes |
| Audyssey DSX | Yes |
| Multichannel Stereo | Yes |
Inputs/Outputs |
|
| Composite In / Out | 2 / 0 |
| Component In / Out | 1 / 0 |
| HDMI In / Out | 7 / 3 |
| Multi-Room Video Out via HDMI | 0 / 0 |
| Analogue In / Fixed Level Out | 3 in / 0 out |
| Phono (MM) In | Yes |
| Digital In: Optical / Coaxial | 2 / 2 |
| Multi-Room Out: analogue / digital | 2 / 0 |
| Multichannel Preamp Out | 7.2 |
| Subwoofer Out | 4 (independent) |
| 7.1 multichannel input | No |
| Number of Speaker Terminals | 13 |
| Speaker A / B | assignable |
| Multi-Room Speaker Terminal | assignable |
| Front Inputs | USB-A |
| USB Audio | Yes / No / No |
| FM Tuner with RDS | Yes |
| DAB+ Tuner | No |
| Multi-Room Video Out: Video / HDMI | 7/3 |
| Analogue In/out | 6/0 |
| Multichannel Pre Out | Yes (13.4) |
| Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB | No / No / No / No / Yes |
HDMI |
|
| Total HDMI Inputs / No. Support 8K | 6 / 3 |
| HDCP2.3 support | Yes |
| HDMI Outputs: Main / Zone | 2 / 1 |
| Analogue to HDMI Video Conversion | No |
| HDMI Upscaling | 1080P/4K to 8K |
| Audio Return Channel | ARC, eARC |
| Video Dynamic Range | HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR |
| ALLM (Auto Low Latency Mode) Pass-through for gaming | Yes |
| Variable Refresh Rate / Quick Frame Transport | Yes / Yes / No |
| HDMI Pass-Through in Standby Mode | Yes |
| CEC | Yes |
| DSD Audio over HDMI | No |
| Auto LipSync | Yes |
| HDMI Inputs: Back / Front | 7 / - |
| Video Conversion Analogue - HDMI | Yes |
| HDMI to HDMI Scaling | 1080P/4K to 8K |
| HDMI 2.1: 8K/60Hz AB / 4K/120Hz AB | Yes / Yes |
| 8K/60Hz AB / 4K/120Hz AB Pass-through In/Out | 7 / 2 (up to 40Gbps) |
| HDMI 2.0: 3D / 4K / CEC / ARC | Yes / Yes / Yes / Yes |
| HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR | |
| Yes / Yes / Yes / Yes / Yes | |
| Variable Refresh Rate / Quick Flame Transport / Quick Media Switching | Yes / Yes / No |
| 8K signal pass-through / scaling / GUI overlay | o / o / o |
| 4K Signal Pass-Through / Scaling / GUI Overlay | o / o / o |
| DSD Audio Capability | Yes |
Performance Technologies |
|
| Copper Plated Chassis | Yes |
| Toroidal Power Supply Transformer | Yes |
| Hyper Dynamic Amplifier Modules (HDAM) (List version) | Yes |
| Pure Direct Mode | Yes |
| Gold Plated RCA Terminals | Yes |
| Clock Jitter Reducer | Yes |
Acoustic/Room Correction |
|
| Audyssey | MultEQ XT32 |
| Audyssey Dynamic EQ / Dynamic Volume | Yes / Yes |
| Audyssey LFC | Yes |
| Dirac Live Support | Yes |
| Variable Cross Over | Yes |
| Optimised Bass Redirection | Yes |
| Bass Sync | Yes |
| Dirac Live Upgradability | Yes |
Music File Support |
|
| Lossy Formats | MP3 / WMA / AAC |
| Lossless formats | FLAC HD 192/24 / WAV 192/24 / ALAC 192/31 |
| DSD Audio | 2.8 MHz / 5.6 MHz |
| Gapless Playback | FLAC, WAV, ALAC, DSD |
| Compressed Audio Enhancer: MDAX2 | Yes |
| Network Audio Sharing | Yes |
Streaming Services |
|
| HEOS Multi-room and Streaming | Yes |
| AirPlay Audio Streaming | AirPlay2 |
| Internet Radio | TuneIn |
| Spotify* | Spotify Connect |
| Pandora | Yes |
| SiriusXM | Yes |
| Other Streaming Services* | Amazon Music HD/ Amazon Music / TIDAL / Deezer / Napster / Soundcloud / Mood Mix |
| Roon tested | Yes |
Network Connectivity |
|
| Ethernet Ports | Yes |
| Wi-Fi (include version / band) | Yes |
| Bluetooth (Include version) | Yes |
| Bluetooth Re-transmit for Bluetooth headphones | Yes |
Smart Home Integration & Control |
|
| Voice Assistant Compatibility | Alexa / Google Voice Assistant / Apple HomePod |
| App for Smart Phones & Tablets (iOS & Android) | Marantz AVR App |
| HEOS Multi-Room Integrated | Yes |
| HEOS Link Compatibility: IR/ IP | Yes /Yes |
| Multi-Room zones | 2 |
| Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analogue | 2 Ch / 2 Ch / Yes / Yes |
| Zone Audio Output: Speaker / Preout | Yes / Yes |
| Zone HDMI Output from HDMI Source | Yes |
| Control Connectivity | IP Control / RS232 Control / Web Control / App Control |
| IR Flasher In | Yes |
| Marantz Remote Bus | Yes |
| DC Trigger Output | 3 |
| HDMI Diagnostics | Yes |
Others |
|
| Front Display | 2 line FLD + port hole OLED |
| GUI Languages | 3 |
| Setup Assistant | Yes |
| Smart Select on Remote | Yes |
| Firmware Update by Network / USB | Yes / Yes |
| ECO Mode | Yes |
| Auto Power off | Yes |
| Sleep Timer | Yes |
| CEC | Yes |
| Auto Speaker Setup by Microphone | Audyssey MultEQ XT32Dirac Live (upgrade) |
| Graphic User Interface - GUI | Modern HD GUIModern HD GUI |
| Smart Select | Yes |
General |
|
| Available Colours | Black/Silver-Gold |
| Metal Front Panel | Yes |
| System Remote Control | RC-051SR |
| Power Consumption | 780W |
| Power Consumption No-Sound (ECO on/off) | 65 W / 110 W |
| Standby Consumption | 0.2W |
| CEC Standby Consumption | 0.5W |
| Network Standby Consumption | Less than 2.0W |
| What's in the box | Main unit, remote control, batteries, AM/FM antennas, wire labels, quick start guide, Audyssey microphone, cardboard microphone stand, 2 External Detachable Antennas, AC cord |
| Pre-Programmed / Learnable / LCD Display | Yes / Yes / Yes |
Производител:
Marantz
Модел:
Cinema 30
Размери - В / Ш / Д:
440 x 401 x 185
Тегло:
15.1
